| Solar Marker Bottle Specifications |
| LIGHT CHARACTERISTICS |
| Light Source |
5𝝓 6 PCS Ultra High Intensity LED |
| Lux Output |
13 Lux(Green) |
| Available LED Colors |
White,Red,Amber,Blue,Green |
| Light Mode Options |
Constant, Flashing |
| Horizontal Output (Degrees) |
35° |
| Vertical Divergence (Degrees) |
+5° |
| LED Life Expectancy (Hours) |
>100,000 Hrs |
| ELECTRICAL CHARACTERISTICS |
| Circuit Protection |
Integrated |
| Nominal Voltage |
1.2V |
| Charging time |
spring,winter/8 hrs ,summer/5 hrs |
| Operating current |
Min 20mA~ Max 25mA |
| Autonomy (hours) ,Constant |
96-108 hrs (On Full Charge) |
| Autonomy (hours) ,Flashing |
240~360 hrs(On Full Charge) |
| Temperature Range |
-20 to 70℃ |
| SOLAR CHARACTERISTICS |
| Solar Module Type |
Multicrystalline or Monocrystalline |
| Solar Cell |
2.5V/180mA |
| Power (watts) |
0.450 watts |
| Solar Module Efficiency (%) |
16-17% |
| POWER SUPPLY |
| Battery Type |
High Grade NiMh - ECO Friendly |
| Battery Size |
1 x AA |
| Battery Capacity (mAhr) |
2300 mAhr |
| Nominal Voltage (v) |
1.2v/ Batter x 1pcs |
| Battery Service Life |
3-5 Years* (Varies with Environment) |
| PHYSICAL CHARACTERISTICS |
| PCB SIZE |
FR4 D 1.6t 62mm x 62mm |
| OPTIONS |
| Custom Options, Sizes, & Colors |
Please Contact |
| Custom Hardware & Mounting |
Please Contact |
| * Information Subject To Change Without Notice |
Part Number
Operating Power
